E-Paper Module
Open Frame / Ready Solution
| Size (cm) |
Size (inch) |
Type | Resolution (X*Y) |
Grey level | Interface | Power Supply | Outline (H*V*D, mm) |
Weight (kg) |
Remark | Image |  |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 33.78 | 13.3 | OP133G | 1200*1600 | 4-bit monochrome (16 Grey Levels) | USB / SPI | 5V DC | 295.7*228.0*10.0 | 0.6 | VESA mount compliant, optional external front light, UV protection | View picture | Download |
| 33.78 | 13.3 | eModule_133 | 1200*1600 | 4-bit monochrome (16 Grey Levels) | Quad band 2G / Dual band 3G /Bluetooth 4.0 LE | 3.5V to 4.2V, with 2A | 440.0*740.0*60.0 | 1.8 | IP67, UV protection, web browser GUI, optionally LED lighting and a photovoltaic cell | View picture | Download |
| 71.12 | 28.0 | OF280G-FL | 3840*1080 | 4-bit monochrome (16 Grey Levels) | USB / SPI, UART for LED front light | 12V DC | 758.0*272.0*22.5 | 3.7 | UV protection, Front light 150 nits, 3mm tempered glass, laminated without air gap | No picture yet | Download |
| 79.25 | 31.2 | OP312G | 2560*1440 | 4-bit monochrome (16 Grey Levels) | USB / SPI | 12V DC | 698.7*405.5*15.0 | 1.6 | VESA mount compliant | View picture | Download |
| 79.25 | 31.2 | eModule_312 | 2560*1440 | 4-bit monochrome (16 Grey Levels) | Quad band 2G / Dual band 3G / WiFi | 3.5V to 4.2V, with 2A | 234.0*334.0*38.0 | 11.2 | IP67, UV protection, web browser GUI, optionally LED lighting and a photovoltaic cell | View picture | Download |
| Size (cm) |
Size (inch) |
Type | Resolution (X*Y) |
Grey level | Interface | Power Supply | Outline (H*V*D, mm) |
Weight (kg) |
Remark | Image | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 33.78 | 13.3 | Place&Play_133 | 1600*1200 | 4-bit monochrome (16 Grey Levels) | WiFi 2.4 GHz | Rechargeable Lithium-Polymer 10,000 mAh battery | 230.0*297.0*10.5 | 0.9 | Available in black and white housing, VESA mount compliant | View picture | Download |
| 79.25 | 31.2 | Place&Play_312 | 2560*1440 | 4-bit monochrome (16 Grey Levels) | WiFi 2.4 GHz | Rechargeable Lithium-Polymer 10,000 mAh battery | 707.2*413.8*13.5 | 6.0 | Available in black and white housing, VESA mount compliant | View picture | Download |
| 79.25 | 31.2 | C07-EPS32-2 | 2560*1440 | 4-bit monochrome (16 Grey Levels) | HDMI/USB/LAN | AC 100-240V, 50/60Hz | 704.0*441.0*33.0 | 4.5 | Battery connection possible, VESA mount compliant | No picture yet | Download |
| 106.68 | 42.0 | C06-EPS42-2 | 2016*2880 | 4-bit monochrome (16 Grey Levels) | HDMI/USB/LAN | AC 100-240V, 50/60Hz | 658.0*880.0*33.0 | 7.4 | Battery connection possible, VESA mount compliant | No picture yet | Download |
| 79.25 | 31.2 | RA-EPD32 | 2560*1440 | 4-bit monochrome (16 Grey Levels) | WLAN/LTE/GPS | 12-24V | 870.0*525.0*36.0 | 15.0 | Battery connection possible, 7mm cover lense, IP6K9K housing made of aluminum and stainless steel | View picture | Download |
| 162.56 | 64.0 | RA-EPD64 | 5120*2280 | 4-bit monochrome (16 Grey Levels) | WLAN/LTE/GPS | 12-24V | 1662.0*906.6*36.0 | 46.0 | Battery connection possible, 7mm cover lense, IP6K9K housing made of aluminum and stainless steel | View picture | Download |
